Cisco Meraki MV23M-HW 8.4 Megapixel Indoor 4K Network Camera - Dome - 98.43 ft Infrared Night Vision - H.264 - 3854 x 2176 - 3 mm- 9 mm Varifocal Lens - 3x Optical - 24 fps - CMOS - Gigabit Ethernet - Wall Mount, Ceiling Mount, Corner Mount - Audio Support - Day/Night, Motion Detection, Vehicle Detection, Human Detection, Privacy Masking, Smart Object Detection, Video Content Analytics, Built-in IR LED, Built-in Microphone, Infrared Detection
- For remote surveillance needs, this network camera is best suited
- Up to 3854 x 2176 video resolution
- CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
- 9 mm maximum focal length for dependable identification distances with better coverage
- f/1.6 maximum aperture for reliable, detailed, and sharp output with added dependability
- 3x optical zoom ensures maximum surveillance productivity without compromising quality
- Provides night vision of objects at a distance of up to 98.43 ft
- 4K recording format for exceptional video quality with maximum productivity
- Infrared night vision type effectively captures visible footage without requiring any external sources of light
- Varifocal lens type to ensure maximum surveillance productivity with added feasibility
General Information
| Manufacturer |
Cisco Systems, Inc |
| Manufacturer Part Number |
MV23M-HW |
| Manufacturer Website Address |
http://www.cisco.com |
| Brand Name |
Cisco Meraki |
| Product Series |
MV23 |
| Product Model |
MV23M-HW |
| Product Name |
MV23M-HW Network Camera |
| Marketing Information |
Overview
The Meraki MV23, part of the third generation of MV smart cameras, combines physical security and advanced analytics in a powerful, yet compact varifocal dome form factor. With an edge architecture that minimizes physical infrastructure and software requirements, MV23 enables faster, easier deployments and greater scalability.
Security in high definition
The ultra-high-performance MV23 series camera supports up to 4K resolution for high-definition video, delivering the level of detail needed to stay on top of what matters.
Compact and easy to install, MV23 series cameras are compatible with a variety of mounting accessories, delivering the right viewing angle wherever they are placed. MV23 series cameras are ideal for monitoring entrances and exits, as well as the general perimeter, from walls, ceilings, or even corner-mount locations.
Using machine-learning-based computer vision, MV23 cameras can perform real-time object detection, classification, and tracking of people and vehicles to increase safety and provide useful insights into activity. These smart cameras deliver powerful business intelligence without compromising physical security.
Product Highlights
- Varifocal lens dome camera
- Robust form factor with 36°-112° horizontal FoV
- More detailed information with up to 4K resolution
- Guaranteed days of video with Smart Retention
- Night vision with IR illumination up to 30 m (98 ft)
- Intelligent motion indexing with search engine
- Built-in analytics likemotion search, motion recap, and motion heatmaps.
- Support forAttribute Search
- Machine-learning capability for intelligent object detection
- Secure video access to ensure privacy with role-based user accounts
- Cloud-augmented edge storage for minimal physical infrastructure
- Built-in automatic security with secure boot and signed firmware, backed by a hardware security chip
- Suitable for deployments of all sizes, from 1-10,000+ cameras
- NDAA Compliant
|
| Product Type |
Network Camera |
Technical Information
| HD Recording |
Yes |
| Recording Formats |
4K |
| Night Vision |
Yes |
| Night Vision Distance |
98.43 ft mm |
| Night Vision Type |
Infrared |
Display & Graphics
| Image Sensor Type |
CMOS |
| Image Sensor Size |
1/2.8" |
| Field of View |
horizontal 36 - 112° |
| Effective Camera Resolution |
8.4 Megapixel |
Video
| Video Formats |
H.264 |
| Maximum Video Resolution |
3854 x 2176 |
| Maximum Frame Rate |
24 fps |
Audio
Lens
| Lens Type |
Varifocal |
| Minimum Focal Length |
3 mm |
| Maximum Focal Length |
9 mm |
| Lens Included |
Yes |
| Minimum Aperture |
f/2.9 |
| Maximum Aperture |
f/1.6 |
| Optical Zoom |
3x |
Exposure
| Shortest Shutter Speed |
1/32000 Second |
| Longest Shutter Speed |
1/30 Second |
Network & Communication
| Connectivity Technology |
Wired |
| Remote Management |
Yes |
| Ethernet Technology |
Gigabit Ethernet |
| Protocols |
TLS |
Storage
| Storage Type |
Solid State Drive |
| Solid State Drive Capacity |
512 GB Byte |
Interfaces/Ports
Power Description
| Maximum Power Consumption |
15.40 W |
| Input Voltage |
24 V AC |
| Input Voltage |
12 V DC |
| Power Source Type |
DC |
| Power Source Type |
AC |
| Power Source Type |
PoE |
Physical Characteristics
| Mount Type |
Wall Mount |
| Mount Type |
Ceiling Mount |
| Mount Type |
Corner Mount |
| Form Factor |
Dome |
| Height |
3.8" mm |
| Diameter |
5.8" mm |
| Weight (Approximate) |
1.85 lb g |
Environmental Conditions
| Minimum Operating Temperature |
32°F (0°C) °F |
| Maximum Operating Temperature |
113°F (45°C) °F |
Miscellaneous
| Features |
Day/Night |
| Features |
Motion Detection |
| Features |
Vehicle Detection |
| Features |
Human Detection |
| Features |
Privacy Masking |
| Features |
Smart Object Detection |
| Features |
Video Content Analytics |
| Features |
Built-in IR LED |
| Features |
Built-in Microphone |
| Features |
Infrared Detection |
| Indoor/Outdoor |
Indoor |
| Package Contents |
- MV23M-HW Network Camera
- Quick-start and installation guide
- MV camera hardware
- Wall-mounting kit
|
Warranty
| Limited Warranty |
5 Year |
| Additional Warranty Information |
Five-year hardware warranty with advanced replacement |
