Eaton DIN24480DC 480VA DIN rail UPS for general purpose power backup, shown mounted on a DIN rail.

100% Genuine

Manufacturer Warranty

Fast US Shipping

Eaton DIN24480DC 480VA DIN Rail UPS

Part Number:

DIN24480DC

207 pieces ready to ship - additional units ship in 7-10 business days.
Estimated shipping in 7–10 business days.
Estimated shipping in 7–10 business days.
Ready to ship.

207 pieces ready to ship - additional units ship in 7-10 business days.

$536.95

USD + Applicable Tax
Visa
Mastercard
American Express
PayPal
Shop Pay

Eaton DIN24480DC 480VA DIN Rail UPS - DIN Rail - 3 Minute Stand-by - 24 V DC Input - 24 V DC Output - Single Phase - LED Display - 1 x Hardwired Receptacle(s)

  • Not for sale in the USA until further notice.
  • Recommended for industrial locations where temperatures range within 0°C and 50°C
  • Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
  • Keeps power running during brief outages to allow time for safe system shutdown
  • Built-in clamp mounts easily to a "top hat" 35mm DIN rail with no mounting screws or brackets required
  • Requires Eaton BPDIN24XL extended battery module for operation (sold separately)
  • Add up to 4 external battery modules (BPDIN24XL) to extend backup runtime

General Information

Manufacturer Eaton Corporation
Manufacturer Part Number DIN24480DC
Manufacturer Website Address http://www.eaton.com
Brand Name Eaton
Product Model DIN24480DC
Product Name DIN24480DC 480VA DIN Rail UPS
Marketing Information

Not for sale in the USA until further notice.

Flexible Power Protection for Smart Industrial Applications

The DIN24480DC standby UPS system with hardwire DC input/output delivers reliable power and battery backup for computing, networking, control and storage equipment in factories, warehouses, edge computing locations and automated manufacturing and fabrication facilities. The rugged compact housing withstands demanding conditions and integrates seamlessly and securely into electrical enclosures in any non-traditional IT environment.

Ideal for Factory Floors and Extreme Temperatures

Get full use of the DIN24480DC's power capacity because there is no derating based on its operating temperature range of 0°C (32°F) to 50°C (122°F), which expands the number of locations in which it can be used. Built to fit into small spaces, the DIN24480DC is a UL 508 recognized component for use in industrial panels. Its pre-installed clamp enables quick mounting to a 35 mm DIN rail. Its fanless design reduces noise and increases reliability.

Reliable Battery Backup Keeps You Operational Through Power Outages

Power outages not only drain productivity from the factory floor, but they also damage expensive equipment. The DIN24480DC protects productivity by providing enough runtime to maintain operation during a brief power outage and protects equipment by allowing it to complete an operation during an extended outage. It also prevents brownouts, overvoltages, surges and line noise from damaging equipment that could destroy data and contribute to costly downtime.

Stay in Control of Your Operation

LEDs on the front panel confirm normal operation and indicate alarm or fault status. Remote on/off can help you avoid maintenance surprises. The DIN24480DC has dry contacts for battery status and UPS communication.

Easy Preventative Maintenance and Initial Troubleshooting

The DIN24480DC requires connection of the BPDIN24XL external battery module (sold separately). Up to four battery modules can be connected to extend backup runtime. The self-test capability can extend the life of the UPS and minimize disruption to operations.
Product Type Standby UPS

Technical Information

Plug/Connector Type Hardwired
Receptacle Type Hardwired
Receptacle Detail 1 x Hardwired
Phase Single Phase
Application/Usage Edge Computing
Application/Usage Network
Application/Usage Storage Device
Application/Usage Factory
Application/Usage Automation Industry
Application/Usage Manufacturing Facility
Application/Usage IT System
Application/Usage Industrial
Application/Usage Machine Control

Power Description

Load Capacity (VA) 480 VA W
Load Capacity (Watt) 480 W
Input Voltage 24 V DC
Output Voltage 24 V DC
Output Power Factor 1.0

Display & Graphics

Display LED

Controls/Indicators

Status Indicators

LED Indicators:

  • POWER (GREEN)
  • LINE MODE ON (SOLID)
  • BATTERY MODE (FLASHING)
  • FAULT (RED) - FLASHING

Interfaces/Ports

EPO Port Yes

Battery Information

DC System Voltage 24 V DC
Battery Characteristics Valve-regulated
Battery Chemistry Lead Acid
Backup/Run Time (Full Load) 3 Minute Second
Backup/Run Time (Half Load) 10 Minute Second

Environmental Conditions

Maximum Operating Elevation 6561 ft mm
Storage Temperature 5°F (-15°C) - 104°F (40°C) °F
Maximum Operating Temperature 122°F (50°C) °F
Sound Emission (A-Weighted) 40 dB(A)

Physical Characteristics

Height 5" mm
Width 1.50" mm
Depth 4.80" mm
Form Factor DIN Rail
Weight (Approximate) 14.40 oz g

Miscellaneous

Package Contents
  • DIN24480DC 480VA DIN Rail UPS
  • Safety Card
  • Owner's Manual
Country of Origin China
Environmentally Friendly Yes
Environmental Compliance Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Environmental Compliance Restriction of Hazardous Substances (RoHS) 3
Environmental Compliance Waste Electrical and Electronic Equipment Directive (WEEE)

Warranty

Limited Warranty 2 Year
