Eaton Tripp Lite HP J4859C compatible SFP transceiver, 1000Base-LX, singlemode LC, 10 km, with DDM, for networking modules

100% Genuine

Manufacturer Warranty

Fast US Shipping

Eaton N286-01GLX-SLX Tripp Lite by Eaton HP J4859C Compatible SFP Transceiver 1000Base-LX DDM Singlemode LC 1310 nm 10 km

Part Number:

N286-01GLX-SLX

155 pieces ready to ship - additional units ship in 7-10 business days.
Estimated shipping in 7–10 business days.
Estimated shipping in 7–10 business days.
Ready to ship.

155 pieces ready to ship - additional units ship in 7-10 business days.

$144.85

USD + Applicable Tax
Visa
Mastercard
American Express
PayPal
Shop Pay

Tripp Lite by Eaton HP J4859C Compatible SFP Transceiver 1000Base-LX DDM Singlemode LC 1310 nm 10 km - For Optical Network, Data Networking 1 LC Female Duplex 1000Base-LX Network - Optical Fiber9/125 µm - Single-mode - 10 Gigabit Ethernet - 1000Base-LX - Hot-pluggable

  • Supports data transfer rates up to 1 Gbps
  • Transmits up to 6 mi. (10 km) with 9/125 SMF cabling
  • Supports Digital Diagnostic Monitoring
  • Complies with MSA standards
  • 100% compatible with HP networking hardware

General Information

Manufacturer Eaton Corporation
Manufacturer Part Number N286-01GLX-SLX
Manufacturer Website Address http://www.eaton.com
Brand Name Tripp Lite series
Product Model N286-01GLX-SLX
Product Name HP N286-01GLX-SLX SFP (mini-GBIC) Module
Marketing Information

The N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver with a duplex LC female connector functions just like the HP J4859C transceiver module and is designed to operate with HP networking equipment. It also meets or exceeds the J4859C's original specifications and complies with MSA (Multi-Source Agreement) standards.

This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling.

The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.

More from the Manufacturer
Product Type SFP (mini-GBIC)

Technical Information

Application/Usage Optical Network
Application/Usage Data Networking

Interfaces/Ports

Total Number of Ports 1
Connector Type LC
Interfaces/Ports Details 1 x LC Duplex 1000Base-LX Network

Media & Performance

Media Type Supported Optical Fiber
Fiber Mode Supported Single-mode
Ethernet Technology 10 Gigabit Ethernet
Network Technology 1000Base-LX

Physical Characteristics

Form Factor Hot-pluggable
Height 0.3" mm
Width 0.5" mm
Depth 2.2" mm
Weight (Approximate) 0.05 lb g

Miscellaneous

Package Contents
  • HP N286-01GLX-SLX SFP (mini-GBIC) Module
  • Owner's manual
Compatibility
  • MSA Compliant
HP Switches:
  • 2920 Switch Series-2920-24G (J9726A#ABA)
  • 2920 Switch Series-2920-24G-PoE+ (J9727A#ABA)
  • 2920 Switch Series-2920-48G (J9728A#ABA)
  • 2920 Switch Series-2920-48G-PoE+ (J9729A#ABA)
  • 5820-14XG-SFP+ 2-slot Switch (JC106A)
  • 5820-24XG-SFP+ Switch (JC102A)
  • 5820AF-24XG Switch (JG219A)
  • HP 1810-8G v2 Smart Desktop Switch-J9802A#ABA
  • HP 1910 Series Switch-1910-24G-PoE (365w)-(JE007AS#ABA)
  • HP 1910-24G-PoE (170W) Switch-JE008AS#ABA
  • HP 2530-24 Switch-J9782A#ABA
  • HP 2530-24G Switch 2530 Series-J9776A#ABA
  • HP 2530-24-PoE+ Ethernet Switch-J9779A#ABA
  • HP 2530-48G Switch-J9775A#ABA
  • HP 2530-48G-PoE+ Switch-J9772A#ABA
  • HP 2920-48G-POE+ Switch-J9836A#ABA
  • ProCurve 2610/E2610 Series Switch-2610-48 (J9088A)
  • ProCurve 2610/E2610 Series Switch-2610-48-PWR (J9089A)
  • Procurve 2615/E2615 Series Switch-2615-8-PoE (J9565A)
  • ProCurve 2620/E2620 Series Switch-2620-24 (J9623A)
  • ProCurve 2620/E2620 Series Switch-2620-24-PoE+ (J9625A#ABA)
  • ProCurve 2620/E2620 Series Switch-2620-24-PPoE+ (J9624A#ABA)
  • ProCurve 2620/E2620 Series Switch-2620-48 (J9626A)
  • ProCurve 2620/E2620 Series Switch-2620-48-PoE+ (J9627A#ABA)
  • ProCurve 2800/E2800 Series Switch-2824 (J4903A)
  • ProCurve 2800/E2800 Series Switch-2848 (J4904A)
  • ProCurve 2810/E2810 Series Switch-2810-24G (J9021A)
  • ProCurve 2810/E2810 Series Switch-2810-48G (J9022A)
  • ProCurve 2900/E2900 Series Switch-2900-24G (J9049A)
  • ProCurve 2900/E2900 Series Switch-2900-48G (J9050A)
  • ProCurve 2910al/E2910al Series Switch - 2910al-24G (J9145A)
  • ProCurve 2910al/E2910al Series Switch - 2910al-24G-PoE+ (J9146A)
  • ProCurve 2910al/E2910al Series Switch - 2910al-48G (J9147A)
  • ProCurve 2910al/E2910al Series Switch - 2910al-48G-PoE+ (J9148A)
  • Procurve 2915/E2915 Series Switch - 2915-8G-PoE (J9562A)
  • ProCurve 3400cl/E3400cl Series Switch - 3400cl-24G (J4905A)
  • ProCurve 3400cl/E3400cl Series Switch - 3400cl-48G (J4906A)
  • Procurve 3500/E3500 Series Switch - 3500-24 Switch (J9470A)
  • Procurve 3500/E3500 Series Switch - 3500-24-PoE+ Switch (J9471A)
  • Procurve 3500/E3500 Series Switch - 3500-48 PoE Switch (J8692A)
  • Procurve 3500/E3500 Series Switch - 3500-48 Switch (J9472A)
  • ProCurve 3500yl/E3500yl Series Switch - 3500yl-24G-PoE+ Switch (J9310A)
  • ProCurve 3500yl/E3500yl Series Switch - 3500yl-24G-PWR (J8692A)
  • ProCurve 3500yl/E3500yl Series Switch - 3500yl-48G-PoE+ Switch (J9311A)
  • ProCurve 3500yl/E3500yl Series Switch - 3500yl-48G-PWR (J8693A)
  • Procurve 3800/E3800 Series Switch - 3800-24G-2SFP+ (J9575A)
  • Procurve 3800/E3800 Series Switch - 3800-24G-PoE+-2SFP+ (J9573A)
  • Procurve 3800/E3800 Series Switch - 3800-24SFP-2SFP+ (J9584A)
  • Procurve 3800/E3800 Series Switch - 3800-48G-4SFP+ (J9576A)
  • Procurve 3800/E3800 Series Switch - 3800-48G-PoE+-4SFP+ (J9574A#ABA)
  • ProCurve 4100gl Series Switch - gl 20-Port 10/100/1000 Module (J4908A)
  • ProCurve 4100gl Series Switch - gl 6-Port Mini-GBIC Module (J4893A)
  • ProCurve 5300xl Series Switch - xl 16-Port 10/100/1000 Module (J4907A)
  • ProCurve 5300xl Series Switch - xl 4-Port Mini-GBIC Module (J4878A/B)
  • ProCurve 5400zl/E5400zl Series Switch - 12-Port Gig-T PoE+/12-Port SFP v2 zl (J9637A)
  • ProCurve 5400zl/E5400zl Series Switch - 20-Port Gig-T PoE+/2-Port SFP+ v2 zl (J9536A)
https://www.tripplite.com/shared/literature/Flyer/n286-01glx-slx-compatibility-list-en.pdf
Country of Origin China
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty 3 Year
