Eaton 9PXPPDM1G2 9PX G2 PowerPass Distribution Module for 3kVA to 6kVA 9PX G2 UPS Systems, L6-30P Input, 1x L6-30R, 1x L14-30R and 6x 5-20R Outlets, 3U Rack/Tower

Name: Eaton 9PXPPDM1G2 9PX G2 PowerPass Distribution Module for 3kVA to 6kVA 9PX G2 UPS Systems, L6-30P Input, 1x L6-30R, 1x L14-30R and 6x 5-20R Outlets, 3U Rack/Tower
Brand: Eaton
SKU: 9PXPPDM1G2
Price: 1827.07 USD
Availability: InStock

Part Number:

9PXPPDM1G2

1 pieces ready to ship - additional units ship in 7-10 business days.

Estimated shipping in 7–10 business days.

Ready to ship.

1 pieces ready to ship - additional units ship in 7-10 business days.

$1,827.07

USD + Applicable Tax

Eaton 9PX G2 PowerPass Distribution Module for 3kVA to 6kVA 9PX G2 UPS Systems, L6-30P Input, 1x L6-30R, 1x L14-30R and 6x 5-20R Outlets, 3U Rack/Tower - NEMA L6-30P - 1 x NEMA L14-30R, 1 x NEMA L6-30R, 6 x NEMA 5-20R - 230 V AC - Surge Protection - 6 ft Cord Length - 3U - Rack-mountable - Rack/Tower

PDU distributes AC power to multiple servers and balances the load on the servers
NEMA 5-20R receptacle type to ensure maximum usability and reliable power output
Single Phase phase PDU provides optimal power output with added usability
NEMA L6-30P plug/connector type for efficient connectivity and feasible power output
230 V AC input voltage for maximum feasibility and added productivity
100 V AC output voltage for optimal performance with maximum feasibility

General Information

Manufacturer	Eaton Corporation
Manufacturer Part Number	9PXPPDM1G2
Manufacturer Website Address	http://www.eaton.com
Brand Name	Eaton
Product Line	PowerPass
Product Model	9PXPPDM1G2
Product Name	PowerPass 9PXPPDM1G2 8-Outlets PDU
Marketing Information	208V to 120V Power Distribution Module Converts High-Voltage Input to Low-Voltage Output The 9PXPPDM1G2 converts your UPS system's 208V high-voltage input to 120V low-voltage output. It features one L6-30R, one L14-30R and six NEMA 5-20R outlets for connecting equipment. Resettable 30A circuit breakers protect against overload conditions. Compatible with Select Eaton UPS Systems The 9PXPPDM1G2 works with Eaton's 9PX5KG2, 9PX6KG2, 9PX6K-L and 9PX3K3UG2 UPS systems. Its front-panel maintenance bypass switch lets you service or replace the UPS system without powering down any equipment and risking costly downtime. All connected equipment remains energized, even while the UPS system is not present. Versatile Installation Options You can mount the 9PXPPDM1G2 in 3U of space in an EIA-standard 19-inch rack using the included 4-post rail kit or an optional 2-post rail kit (RK2PC, sold separately). You can also adapt it for tower installation using the included joining bracket and hardware. The 10-foot power cord with L6-30P plug connects to a compatible AC outlet.
Product Type	PDU

Technical Information

Phase	Single Phase
Plug/Connector Type	NEMA L6-30P
Receptacle Type	NEMA 5-20R
Receptacle Type	NEMA L14-30R
Receptacle Type	NEMA L6-30R
Receptacle Detail	1 x NEMA L14-30R
Receptacle Detail	1 x NEMA L6-30R
Receptacle Detail	6 x NEMA 5-20R
Protection Type	Surge Protection
Load Capacity (VA)	6000 W
Load Capacity (Watt)	6000 W

Power Description

Input Voltage	230 V AC
Output Voltage	100 V AC
Output Voltage	110 V AC
Output Voltage	120 V AC
Output Voltage	208 V AC
Output Voltage	220 V AC
Output Voltage	230 V AC
Output Voltage	240 V AC
Power Source	UPS
Input Current	30 A
Input Frequency	60 Hz

Physical Characteristics

Color Family	Black
Product Color	Black
Mount Type	Rack-mountable
Form Factor	Rack/Tower
Rack Height	3U
Cord Length	6 ft mm
Height	5.1" mm
Width	17.3" mm
Depth	25" mm

Environmental Conditions

Minimum Operating Temperature	32°F (0°C) °F
Maximum Operating Temperature	104°F (40°C) °F

Miscellaneous

Package Contents	PowerPass 9PXPPDM1G2 8-Outlets PDU Joining Bracket And Hardware For Tower Configuration Rack-mounting Hardware Owner's Manuals
Application/Usage	UPS
Energy Star	Yes
Country of Origin	Philippines
Environmental Compliance	Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty

3 Year
