Vertiv VP4N30AH Geist rPDU MN05M4W1-36MR99-3TL14A0A10-S 36-Outlets PDU

100% Genuine

Manufacturer Warranty

Fast US Shipping

Vertiv VP4N30AH Geist rPDU MN05M4W1-36MR99-3TL14A0A10-S 36-Outlets PDU

Part Number:

VP4N30AH

1 pieces ready to ship - additional units ship in 7-10 business days.
Estimated shipping in 7–10 business days.
Estimated shipping in 7–10 business days.
Ready to ship.

1 pieces ready to ship - additional units ship in 7-10 business days.

$1,164.96

USD + Applicable Tax
Visa
Mastercard
American Express
PayPal
Shop Pay

Vertiv Geist rPDU MN05M4W1-36MR99-3TL14A0A10-S 36-Outlets PDU - Monitored - NEMA L14-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19, 12 x NEMA 5-20R - 120 V AC, 230 V AC - Overcurrent Protection, Double Pole - Network (RJ-45) - 10 ft Cord Length - Vertical - Rack-mountable - TAA Compliant

  • PDU allows power to be more efficiently distributed and controlled
  • Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
  • IEC 60320 C13 receptacle type to ensure maximum dependability and optimal performance
  • NEMA L14-30P plug/connector type for efficient connectivity and feasible power output
  • 120 V AC input voltage for maximum feasibility and added productivity
  • 208 V AC output voltage for optimal performance with maximum feasibility

General Information

Manufacturer Vertiv
Manufacturer Part Number VP4N30AH
Manufacturer Website Address http://www.vertiv.com/
Brand Name Vertiv Geist
Product Series rPDU
Product Model MN05M4W1-36MR99-3TL14A0A10-S
Product Name rPDU MN05M4W1-36MR99-3TL14A0A10-S 36-Outlets PDU
Marketing Information

Upgradeable Unit Level EC Monitored rPDUs provide reliable power distribution to critical IT equipment while delivering a comprehensive view of input level power usage via remote network access. Includes environmental monitoring capabilities to obtain realtime environmental metrics. Upgrade the hot-swappable monitoring device on select units to leverage new technologies and accommodate changing business needs.

Benefits

  • Reliable power distribution with local and remote power monitoring options offer quick access to critical power usage information to evaluate energy usage trends and maximize uptime
  • Environmental monitoring capabilities with the addition of optional environmental sensors ensure users have critical infrastructure data at their fingertips to prevent climate-related equipment failure and system downtime.
  • Fault-Tolerant Daisy Chaining with RSTP simplifies intelligent rPDU connectivity and ensures data is reported even when a breakin the network chain occurs. Supports up to 40 rPDUs.
  • Every unit is 100% tested for reliability and functionality.
  • Daisy-chain up to 50 devices on a single IP address and reduce deployment time with self-configuration of downstream devices.
Product Type PDU

Technical Information

PDU Type Monitored
Plug/Connector Type NEMA L14-30P
Plug/Connector Detail 1 x NEMA L14-30P
Receptacle Type IEC 60320 C13
Receptacle Type IEC 60320 C19
Receptacle Type NEMA 5-20R
Receptacle Detail 20 x IEC 60320 C13
Receptacle Detail 4 x IEC 60320 C19
Receptacle Detail 12 x NEMA 5-20R
Protection Type Overcurrent Protection
Protection Type Double Pole
Features LED Display
Features Touch Screen Display
Load Capacity (Watt) 5700 W

Power Description

Input Voltage 120 V AC
Input Voltage 230 V AC
Input Voltage Range 100 V AC - 120 V AC
Input Voltage Range 200 V AC - 240 V AC
Output Voltage 208 V AC
Output Voltage 120 V AC
Power Rating (Watt) 5700 W
Input Current 30 A
Input Frequency 60 Hz

Management

Management
  • DHCP
  • HTTP
  • HTTPS
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RADIUS
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Syslog
  • TACACS+
  • Modbus TCP
  • Journal de données CSV
  • API JSON
  • Journal de données JSON

Interfaces/Ports

Network (RJ-45) Yes

Physical Characteristics

Color Family Black
Product Color Black Powder Coat
Mounting Orientation Vertical
Mount Type Rack-mountable
Cord Length 10 ft mm
Width 2" mm
Depth 2" mm
Length 70" mm

Environmental Conditions

Maximum Operating Temperature 140°F (60°C) °F

Miscellaneous

Package Contents
  • rPDU MN05M4W1-36MR99-3TL14A0A10-S 36-Outlets PDU
  • Vertical Mounting Bracket Kit
Application/Usage IT Equipment
Country of Origin United States
TAA Compliant Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty 5 Year
Additional Warranty Information

5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
